1T0A

Crystal Structure of 2C-Methyl-D-Erythritol-2,4-cyclodiphosphate Synthase from Shewanella Oneidensis


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.6 Å
  • R-Value Free: 0.193
  • R-Value Work: 0.174

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structure of 2C-methyl-D-erythritol-2,4-cyclodiphosphate synthase from Shewanella oneidensis at 1.6 A: identification of farnesyl pyrophosphate trapped in a hydrophobic cavity.

Ni, S.Robinson, H.Marsing, G.C.Bussiere, D.E.Kennedy, M.A.

(2004) Acta Crystallogr.,Sect.D 60: 1949-1957

  • DOI: 10.1107/S0907444904021791

  • PubMed Abstract:
  • Isopentenyl pyrophosphate (IPP) is a universal building block for the ubiquitous isoprenoids that are essential to all organisms. The enzymes of the non-mevalonate pathway for IPP synthesis, which is unique to many pathogenic bacteria, have recently ...

    Isopentenyl pyrophosphate (IPP) is a universal building block for the ubiquitous isoprenoids that are essential to all organisms. The enzymes of the non-mevalonate pathway for IPP synthesis, which is unique to many pathogenic bacteria, have recently been explored as targets for antibiotic development. Several crystal structures of 2C-methyl-D-erythritol-2,4-cyclophosphate (MECDP) synthase, the fifth of seven enzymes involved in the non-mevalonate pathway for synthesis of IPP, have been reported; however, the composition of metal ions in the active site and the presence of a hydrophobic cavity along the non-crystallographic threefold symmetry axis has varied between the reported structures. Here, the structure of MEDCP from Shewanella oneidensis MR1 (SO3437) was determined to 1.6 A resolution in the absence of substrate. The presence of a zinc ion in the active-site cleft, tetrahedrally coordinated by two histidine side chains, an aspartic acid side chain and an ambiguous fourth ligand, was confirmed by zinc anomalous diffraction. Based on analysis of anomalous diffraction data and typical metal-to-ligand bond lengths, it was concluded that an octahedral sodium ion was 3.94 A from the zinc ion. A hydrophobic cavity was observed along the threefold non-crystallographic symmetry axis, filled by a well defined non-protein electron density that could be modeled as farnesyl pyrophosphate (FPP), a downstream product of IPP, suggesting a possible feedback mechanism for enzyme regulation. The high-resolution data clarified the FPP-binding mode compared with previously reported structures. Multiple sequence alignment indicated that the residues critical to the formation of the hydrophobic cavity and for coordinating the pyrophosphate group of FPP are present in the majority of MEDCP synthase enzymes, supporting the idea of a specialized biological function related to FPP binding in a subfamily of MEDCP synthase homologs.


    Organizational Affiliation

    Pacific Northwest National Laboratory, Biological Sciences Division, Richland, WA 99352, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
2C-methyl-D-erythritol 2,4-cyclodiphosphate synthase
A, B, C
159Shewanella oneidensis (strain MR-1)Mutation(s): 0
Gene Names: ispF
EC: 4.6.1.12
Find proteins for Q8EBR3 (Shewanella oneidensis (strain MR-1))
Go to UniProtKB:  Q8EBR3
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A, B, C
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
FPP
Query on FPP

Download SDF File
Download CCD File
A
FARNESYL DIPHOSPHATE
C15 H28 O7 P2
VWFJDQUYCIWHTN-YFVJMOTDSA-N
 Ligand Interaction
CO
Query on CO

Download SDF File
Download CCD File
A, B, C
COBALT (II) ION
Co
XLJKHNWPARRRJB-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A, B, C
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.6 Å
  • R-Value Free: 0.193
  • R-Value Work: 0.174
  • Space Group: P 43 21 2
Unit Cell:
Length (Å)Angle (°)
a = 117.088α = 90.00
b = 117.088β = 90.00
c = 108.937γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
HKL-2000data reduction
REFMACrefinement
MOLREPphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2004-10-26
    Type: Initial release
  • Version 1.1: 2008-04-30
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Source and taxonomy, Version format compliance
