1SEK

THE STRUCTURE OF ACTIVE SERPIN K FROM MANDUCA SEXTA AND A MODEL FOR SERPIN-PROTEASE COMPLEX FORMATION


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.199
  • R-Value Observed: 0.199

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

The structure of active serpin 1K from Manduca sexta.

Li, J.Wang, Z.Canagarajah, B.Jiang, H.Kanost, M.Goldsmith, E.J.

(1999) Structure 7: 103-109

  • DOI: https://doi.org/10.1016/s0969-2126(99)80013-6
  • Primary Citation of Related Structures:
    1SEK

  • PubMed Abstract:

    The reactive center loops (RCL) of serpins undergo large conformational changes triggered by the interaction with their target protease. Available crystallographic data suggest that the serpin RCL is polymorphic, but the relevance of the observed conformations to the competent active structure and the conformational changes that occur on binding target protease has remained obscure. New high-resolution data on an active serpin, serpin 1K from the moth hornworm Manduca sexta, provide insights into how active serpins are stabilized and how conformational changes are induced by protease binding. The 2.1 A structure shows that the RCL of serpin 1K, like that of active alpha1-antitrypsin, is canonical, complimentary and ready to bind to the target protease between P3 and P3 (where P refers to standard protease nomenclature),. In the hinge region (P17-P13), however, the RCL of serpin 1K, like ovalbumin and alpha1-antichymotrypsin, forms tight interactions that stabilize the five-stranded closed form of betasheet A. These interactions are not present in, and are not compatible with, the observed structure of active alpha1-antitrypsin. Serpin 1K may represent the best resting conformation for serpins - canonical near P1, but stabilized in the closed conformation of betasheet A. By comparison with other active serpins, especially alpha1-antitrypsin, a model is proposed in which interaction with the target protease near P1 leads to conformational changes in betasheet A of the serpin.


  • Organizational Affiliation

    Department of Biochemistry, The University of Texas Southwestern Medical Center at Dallas, 5323 Harry Hines Boulevard, Dallas, Texas 75235, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
SERPIN K378Manduca sextaMutation(s): 0
UniProt
Find proteins for Q25526 (Manduca sexta)
Explore Q25526
Go to UniProtKB:  Q25526
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ25526
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.199
  • R-Value Observed: 0.199
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 125.96α = 90
b = 42.05β = 117.6
c = 76.05γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1999-03-23
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-02-14
    Changes: Data collection, Database references, Other
