1S48

Crystal structure of RNA-dependent RNA polymerase construct 1 (residues 71-679) from BVDV


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.282
  • R-Value Work: 0.229
  • R-Value Observed: 0.229

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

The structure of the RNA-dependent RNA polymerase from bovine viral diarrhea virus establishes the role of GTP in de novo initiation.

Choi, K.H.Groarke, J.M.Young, D.C.Kuhn, R.J.Smith, J.L.Pevear, D.C.Rossmann, M.G.

(2004) Proc Natl Acad Sci U S A 101: 4425-4430

  • DOI: 10.1073/pnas.0400660101
  • Primary Citation of Related Structures:
    1S48, 1S49, 1S4F

  • PubMed Abstract:
  • The bovine viral diarrhea virus (BVDV) RNA-dependent RNA polymerase can initiate RNA replication by a de novo mechanism without a primer. The structure of BVDV polymerase, determined to 2.9-A resolution, contains a unique N-terminal domain, in addition to the fingers, palm, and thumb domains common to other polymerases ...

    The bovine viral diarrhea virus (BVDV) RNA-dependent RNA polymerase can initiate RNA replication by a de novo mechanism without a primer. The structure of BVDV polymerase, determined to 2.9-A resolution, contains a unique N-terminal domain, in addition to the fingers, palm, and thumb domains common to other polymerases. The structure of BVDV polymerase complexed with GTP, which is required for de novo (primer-independent) initiation, shows that GTP binds adjacent to the initiation NTP, suggesting that the GTP mimics a vestigial RNA product. Comparison of five monomers in two different crystal forms showed conformational changes in the fingertip region and in the thumb domain that may help to translocate the RNA template and product strands during elongation. The putative binding sites of previously reported BVDV inhibitors are also discussed.


    Organizational Affiliation

    Department of Biological Sciences, Purdue University, 915 West State Street, West Lafayette, IN 47907, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
RNA-dependent RNA polymeraseA609Bovine viral diarrhea virus 1Mutation(s): 12
Gene Names: NS5B
EC: 3.4.22 (UniProt), 3.4.21.113 (UniProt), 3.6.1.15 (UniProt), 3.6.4.13 (UniProt), 2.7.7.48 (UniProt)
UniProt
Find proteins for P19711 (Bovine viral diarrhea virus (isolate NADL))
Explore P19711
Go to UniProtKB:  P19711
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP19711
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.282
  • R-Value Work: 0.229
  • R-Value Observed: 0.229
  • Space Group: P 62 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 205.727α = 90
b = 205.727β = 90
c = 99.597γ = 120
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data reduction
SCALEPACKdata scaling
SOLVEphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-04-06
    Type: Initial release
  • Version 1.1: 2008-04-29
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
