1O4X

TERNARY COMPLEX OF THE DNA BINDING DOMAINS OF THE OCT1 AND SOX2 TRANSCRIPTION FACTORS WITH A 19MER OLIGONUCLEOTIDE FROM THE HOXB1 REGULATORY ELEMENT

Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 1
  • Selection Criteria: REGULARIZED MEAN STRUCTURE

wwPDB Validation   3D Report Full Report

Currently 1O4X does not have a validation slider image.


This is version 1.3 of the entry. See complete history.


Literature

Molecular basis for synergistic transcriptional activation by Oct1 and Sox2 revealed from the solution structure of the 42-kDa Oct1.Sox2.Hoxb1-DNA ternary transcription factor complex.

Williams, D.C., Cai, M., Clore, G.M.

(2004) J Biol Chem 279: 1449-1457

  • DOI: https://doi.org/10.1074/jbc.M309790200
  • Primary Citation of Related Structures:
    1O4X

  • PubMed Abstract:

    • The Oct and Sox transcription factors control many different aspects of neural development and embryogenesis, often binding to adjacent sites on DNA, and interacting with one another through their DNA binding domains to regulate transcription synergistically ...

    The Oct and Sox transcription factors control many different aspects of neural development and embryogenesis, often binding to adjacent sites on DNA, and interacting with one another through their DNA binding domains to regulate transcription synergistically. Oct proteins contain two DNA binding domains (POUS and POUHD) connected by a flexible linker, which interact with DNA in a bipartite manner. Residual dipolar coupling measurements on the binary Oct1.DNA complex reveal that the two domains are characterized by distinct alignment tensors in both phage pf1 and polyethylene glycol/hexanol liquid crystalline media. We show that this difference is due to a fast microscopic dissociation/association process involving alternative binding modes for the weaker binding POUS domain in the binary complex. Upon binding of Sox2 to an adjacent site in the Hoxb1 regulatory element, all components of the ternary Oct1.Sox2.DNA complex share a single alignment tensor. Thus ternary complex formation increases the site-specific affinity of Oct1 for DNA by effectively locking the POUS domain in a single orientation on the DNA. The solution NMR structure of the ternary 42 kDa Oct1.Sox2.Hoxb1-DNA complex, determined by novel procedures based on orientational restraints from dipolar couplings and conjoined rigid body/torsion angle dynamics, reveals that Sox2 and POUS interact through a predominantly hydrophobic interface, surrounded by a ring of electrostatic interactions. These observations suggest a mechanism of combinatorial control involving direct protein-protein interactions on the DNA whereby Oct1 in conjunction with a co-interacting transcription factor provide cell-specific transcription regulation.

    Organizational Affiliation:

    Laboratory of Chemical Physics, NIDDK, National Institutes of Health, Bethesda, Maryland 20892-0520, USA.



Macromolecules

Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
transcription factor Oct-1C [auth A]167Homo sapiensMutation(s): 1
Gene Names: POU2F1, OCT1, OTF1
UniProt & NIH Common Fund Data Resources
Find proteins for P14859 (Homo sapiens)
Explore P14859
Go to UniProtKB:  P14859
PHAROS:  P14859
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP14859
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription factor SOX-2D [auth B]88Homo sapiensMutation(s): 0
Gene Names: SOX2
UniProt & NIH Common Fund Data Resources
Find proteins for P48431 (Homo sapiens)
Explore P48431
Go to UniProtKB:  P48431
PHAROS:  P48431
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP48431
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChainsLengthOrganismImage
5'-D(*TP*GP*TP*CP*TP*TP*TP*GP*TP*CP*AP*TP*GP*CP*TP*AP*AP*TP*G)-3'A [auth C]19N/A
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsLengthOrganismImage
5'-D(*CP*AP*TP*TP*AP*GP*CP*AP*TP*GP*AP*CP*AP*AP*AP*GP*AP*CP*A)-3'B [auth D]19N/A
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 1
  • Selection Criteria: REGULARIZED MEAN STRUCTURE

Structure Validation

View Full Validation Report

Currently 1O4X does not have a validation slider image.



View more in-depth experimental data
Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-01-27
    Type: Initial release
  • Version 1.1: 2008-04-26
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2021-10-27
    Changes: Data collection, Database references, Derived calculations
