Elaborate Manifold of Short Hydrogen Bond Arrays Mediating Binding of Active Site-Directed Serine Protease Inhibitors

Experimental Data Snapshot

  • Resolution: 1.45 Å
  • R-Value Free: 0.219
  • R-Value Work: 0.198
  • R-Value Observed: 0.200

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.4 of the entry. See complete history


Elaborate manifold of short hydrogen bond arrays mediating binding of active site-directed serine protease inhibitors.

Katz, B.A.Elrod, K.Verner, E.Mackman, R.L.Luong, C.Shrader, W.D.Sendzik, M.Spencer, J.R.Sprengeler, P.A.Kolesnikov, A.Tai, V.W.Hui, H.C.Breitenbucher, J.G.Allen, D.Janc, J.W.

(2003) J Mol Biol 329: 93-120

  • DOI: https://doi.org/10.1016/s0022-2836(03)00399-1
  • Primary Citation of Related Structures:
    1O2G, 1O2H, 1O2I, 1O2J, 1O2K, 1O2L, 1O2M, 1O2N, 1O2O, 1O2P, 1O2Q, 1O2R, 1O2S, 1O2T, 1O2U, 1O2V, 1O2W, 1O2X, 1O2Y, 1O2Z, 1O30, 1O31, 1O32, 1O33, 1O34, 1O35, 1O36, 1O37, 1O38, 1O39, 1O3A, 1O3B, 1O3C, 1O3D, 1O3E, 1O3F, 1O3G, 1O3H, 1O3I, 1O3J, 1O3K, 1O3L, 1O3M, 1O3N, 1O3O, 1O3P

  • PubMed Abstract:

    An extensive structural manifold of short hydrogen bond-mediated, active site-directed, serine protease inhibition motifs is revealed in a set of over 300 crystal structures involving a large suite of small molecule inhibitors (2-(2-phenol)-indoles and 2-(2-phenol)-benzimidazoles) determined over a wide range of pH (3.5-11.4). The active site hydrogen-bonding mode was found to vary markedly with pH, with the steric and electronic properties of the inhibitor, and with the type of protease (trypsin, thrombin or urokinase type plasminogen activator (uPA)). The pH dependence of the active site hydrogen-bonding motif is often intricate, constituting a distinct fingerprint of each complex. Isosteric replacements or minor substitutions within the inhibitor that modulate the pK(a) of the phenol hydroxyl involved in short hydrogen bonding, or that affect steric interactions distal to the active site, can significantly shift the pH-dependent structural profile characteristic of the parent scaffold, or produce active site-binding motifs unique to the bound analog. Ionization equilibria at the active site associated with inhibitor binding are probed in a series of the protease-inhibitor complexes through analysis of the pH dependence of the structure and environment of the active site-binding groups involved in short hydrogen bond arrays. Structures determined at high pH (>11), suggest that the pK(a) of His57 is dramatically elevated, to a value as high as approximately 11 in certain complexes. K(i) values involving uPA and trypsin determined as a function of pH for a set of inhibitors show pronounced parabolic pH dependence, the pH for optimal inhibition governed by the pK(a) of the inhibitor phenol involved in short hydrogen bonds. Comparison of structures of trypsin, thrombin and uPA, each bound by the same inhibitor, highlights important structural variations in the S1 and active sites accessible for engineering notable selectivity into remarkably small molecules with low nanomolar K(i) values.

  • Organizational Affiliation

    Celera, 180 Kimball Way, South San Francisco, CA 94080, USA. brad.katz@celera.com

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
BETA-TRYPSIN223Bos taurusMutation(s): 0
Find proteins for P00760 (Bos taurus)
Explore P00760
Go to UniProtKB:  P00760
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00760
Sequence Annotations
  • Reference Sequence
Small Molecules
Binding Affinity Annotations
IDSourceBinding Affinity
CR9 PDBBind:  1O2R Ki: 6100 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Resolution: 1.45 Å
  • R-Value Free: 0.219
  • R-Value Work: 0.198
  • R-Value Observed: 0.200
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 63.75α = 90
b = 63.52β = 90
c = 69.23γ = 90
Software Package:
Software NamePurpose
bioteXdata collection
bioteXdata reduction
bioteXdata scaling
Quantamodel building

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2003-09-02
    Type: Initial release
  • Version 1.1: 2008-04-26
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-10-04
    Changes: Refinement description
  • Version 1.4: 2023-12-27
    Changes: Data collection, Database references, Derived calculations
