1N73

Fibrin D-Dimer, Lamprey complexed with the PEPTIDE LIGAND: GLY-HIS-ARG-PRO-AMIDE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.289
  • R-Value Work: 0.258
  • R-Value Observed: 0.260

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

The Crystal structure of fragment double-D from cross-linked lamprey fibrin reveals isopeptide linkages across an unexpected D-D interface

Yang, Z.Pandi, L.Doolittle, R.F.

(2002) Biochemistry 41: 15610-15617

  • DOI: 10.1021/bi026666i
  • Primary Citation of Related Structures:
    1N73, 1N86, 1N8E

  • PubMed Abstract:
  • The crystal structure of fragment double-D from factor XIII-cross-linked lamprey fibrin has been determined at 2.9 A resolution. The 180 kDa covalent dimer was cocrystallized with the peptide Gly-His-Arg-Pro-amide, which in many fibrinogens, but not that of lamprey, corresponds to the B-knob exposed by thrombin ...

    The crystal structure of fragment double-D from factor XIII-cross-linked lamprey fibrin has been determined at 2.9 A resolution. The 180 kDa covalent dimer was cocrystallized with the peptide Gly-His-Arg-Pro-amide, which in many fibrinogens, but not that of lamprey, corresponds to the B-knob exposed by thrombin. The structure was determined by molecular replacement, a recently determined structure of lamprey fragment D being used as a search model. GHRPam was found in both the gamma- and beta-chain holes. Unlike the situation with fragment D, the crystal packing of the cross-linked double-D structure exhibits two different D-D interfaces, each gamma-chain facing gamma-chains on two other molecules. One of these (interface I) involves the asymmetric interface observed in all other D fragments and related structures. The other (interface II) encompasses a completely different set of residues. The two abutments differ in that interface I results in an "in line" arrangement of abutting molecules and the interface II in a "zigzag" arrangement. So far as can be determined (the electron density could only be traced on one side of the cross-links), it is the gamma-chains of the newly observed zigzag units (interface II) that are joined by the reciprocal epsilon-amino-gamma-glutamyl cross-links. Auspiciously, the same novel D-D interface was observed in two lower-resolution crystal structures of human double-D preparations that had been crystallized under unusual circumstances. These observations show that double-D structures are linked in a way that is sufficiently flexible to accommodate different D-D interfaces under different circumstances.


    Organizational Affiliation

    Center for Molecular Genetics, University of California at San Diego, La Jolla, CA 92093-0634, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Fibrin alpha-1 chainA, D119Petromyzon marinusMutation(s): 0
UniProt
Find proteins for P02674 (Petromyzon marinus)
Explore P02674
Go to UniProtKB:  P02674
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Fibrin beta chainB, E323Petromyzon marinusMutation(s): 0
UniProt
Find proteins for P02678 (Petromyzon marinus)
Explore P02678
Go to UniProtKB:  P02678
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
Fibrin gamma chainC, F330Petromyzon marinusMutation(s): 0
Gene Names: FGG
UniProt
Find proteins for P04115 (Petromyzon marinus)
Explore P04115
Go to UniProtKB:  P04115
Protein Feature View
Expand
  • Reference Sequence
  • Find similar proteins by:  Sequence   |   Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
peptide ligand: Gly-his-Arg-Pro-amideG, H, I, J4N/AMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P02675 (Homo sapiens)
Explore P02675
Go to UniProtKB:  P02675
PHAROS:  P02675
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.289
  • R-Value Work: 0.258
  • R-Value Observed: 0.260
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 49.732α = 99.58
b = 99.302β = 101.46
c = 120.732γ = 92.36
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
AMoREphasing
CNSrefinement

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-01-07
    Type: Initial release
  • Version 1.1: 2008-04-28
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 1.3: 2017-03-08
    Changes: Derived calculations
  • Version 1.4: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Data collection, Derived calculations, Structure summary
