Experimental Data Snapshot

  • Resolution: 1.90 Å
  • R-Value Work: 0.189
  • R-Value Observed: 0.189

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Stabilization of a strained protein loop conformation through protein engineering.

Hodel, A.Kautz, R.A.Fox, R.O.

(1995) Protein Sci 4: 484-495

  • DOI: https://doi.org/10.1002/pro.5560040315
  • Primary Citation of Related Structures:
    1KDA, 1KDB, 1KDC

  • PubMed Abstract:

    Staphylococcal nuclease is found in two folded conformations that differ in the isomerization of the Lys 116-Pro 117 peptide bond, resulting in two different conformations of the residue 112-117 loop. The cis form is favored over the trans with an occupancy of 90%. Previous mutagenesis studies have shown that when Lys 116 is replaced by glycine, a trans conformation is stabilized relative to the cis conformation by the release of steric strain in the trans form. However, when Lys 116 is replaced with alanine, the resulting variant protein is identical to the wild-type protein in its structure and in the dominance of the cis configuration. The results of these studies suggested that any nuclease variant with a non-glycine residue at position 116 should also favor the cis form because of steric requirements of the beta-carbon at this position. In this report, we present a structural analysis of four nuclease variants with substitutions at position 116. Two variants, K116E and K116M, follow the "beta-carbon" hypothesis by favoring the cis form. Furthermore, the crystal structure of K116E is nearly identical to that of the wild-type protein. Two additional variants, K116D and K116N, provide exceptions to this simple "beta-carbon" rule in that the trans conformation is stabilized relative to the cis configuration by these substitutions. Crystallographic data indicate that this stabilization is effected through the addition of tertiary interactions between the side chain of position 116 with the surrounding protein and water structure. The detailed trans conformation of the K116D variant appears to be similar to the trans conformation observed in the K116G variant, suggesting that these two mutations stabilize the same conformation but through different mechanisms.

  • Organizational Affiliation

    Department of Molecular Biophysics and Biochemistry, Yale University, New Haven, Connecticut 06511, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
STAPHYLOCOCCAL NUCLEASE149Staphylococcus aureusMutation(s): 0
Gene Names: nuc
Find proteins for P00644 (Staphylococcus aureus)
Explore P00644
Go to UniProtKB:  P00644
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00644
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.90 Å
  • R-Value Work: 0.189
  • R-Value Observed: 0.189
  • Space Group: P 41
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.2α = 90
b = 48.2β = 90
c = 63.1γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1995-02-27
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
