Biological Assembly 1

 3D View: Structure

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 67.21 kDa
• Atom Count: 5001
• Residue Count: 589
• Unique protein chains: 1

1JI6

CRYSTAL STRUCTURE OF THE INSECTICIDAL BACTERIAL DEL ENDOTOXIN CRY3Bb1 BACILLUS THURINGIENSIS

• DOI: 10.2210/pdb1JI6/pdb

• Classification: TOXIN
• Organism(s): Bacillus thuringiensis
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2001-06-29 Released: 2001-09-19
• Deposition Author(s): Cody, V.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free: 0.253
• R-Value Work: 0.175
• R-Value Observed: 0.175

Literature

Structure of the insecticidal bacterial delta-endotoxin Cry3Bb1 of Bacillus thuringiensis.

Galitsky, N., Cody, V., Wojtczak, A., Ghosh, D., Luft, J.R., Pangborn, W., English, L.

(2001) Acta Crystallogr D Biol Crystallogr 57: 1101-1109

• PubMed: 11468393
• DOI: 10.1107/s0907444901008186
• Structures With Same Primary Citation


• PubMed Abstract:


The coleopteran-active delta-endotoxin Cry3Bb1 from Bacillus thuringiensis (Bt) strain EG7231 is uniquely toxic to Diabrotica undecimpunctata, the Southern corn rootworm, while retaining activity against Leptinotarsa decemlineata, the Colorado potato beetle. The crystal structure of the delta-endotoxin Cry3Bb1 has been refined using data collected to 2.4 A resolution, with a residual R factor of 17.5% and an R(free) of 25.3%. The structure is made up of three domains: I, a seven-helix bundle (residues 64-294); II, a three-sheet domain (residues 295-502); and III, a beta-sandwich domain (residues 503-652). The monomers in the orthorhombic C222(1) crystal lattice form a dimeric quaternary structure across a crystallographic twofold axis, with a channel formed involving interactions between domains I and III. There are 23 hydrogen bonds between the two monomers conferring structural stability on the dimer. It has been demonstrated that Cry3Bb1 and the similar toxin Cry3A form oligomers in solution. The structural results presented here indicate that the interactions between domains I and III could be responsible for the initial higher order structure and have implications for the biological activity of these toxins. There are seven additional single amino-acid residues in the sequence of Cry3Bb1 compared with that of Cry3A; one in domain I, two in domain II and four in domain III, which also shows the largest conformational difference between the two proteins. These changes can be implicated in the selectivity differences noted for these two delta-endotoxins.

---

Related Citations:

• Crystal Structure of Insecticidal Delta-Endotoxin from Bacillus Thuringiensis at 2.5 Angstroms Resolution
  Li, J., Carroll, J., Ellar, D.J.
  (1991) Nature 353: 815

• X-Ray Analysis of the Crystalline Parasporal Inclusion in Bacillus Thuringiensis Var. Tenebrionis
  Li, J., Henderson, R., Carroll, J., Ellar, D.
  (1988) J Mol Biol 199: 543

---

Organizational Affiliation:

Hauptman-Woodward Research Institute, Inc., 73 High Street, Buffalo, NY 14203-1196, USA.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details
PESTICIDIAL CRYSTAL PROTEIN CRY3BB	A	589	Bacillus thuringiensis	Mutation(s): 0  Gene Names: cry3Bb, cryIIIB(b), cryIIIb2
Find proteins for Q06117 (Bacillus thuringiensis) Go to UniProtKB:  Q06117

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free: 0.253
• R-Value Work: 0.175
• R-Value Observed: 0.175
• Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 122.44	α = 90
b = 131.81	β = 90
c = 105.7	γ = 90

Software Package:

Software Name	Purpose
X-PLOR	model building
X-PLOR	refinement
SCALEPACK	data scaling
X-PLOR	phasing

Structure Validation

Entry History

Deposition Data

• Deposited Date: 2001-06-29
• Released Date: 2001-09-19
Deposition Author(s): Cody, V.

Revision History

• Version 1.0: 2001-09-19
  Type: Initial release

• Version 1.1: 2008-04-27
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Version format compliance
• Version 1.3: 2017-10-04
  Changes: Refinement description
