1IP0 | pdb_00001ip0

NMR STRUCTURE OF HUMAN BETACELLULIN-2


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 50
  • Conformers Submitted:
  • Selection Criteria: structures with the lowest energy

wwPDB Validation 3D Report Full Report

Validation slider image for 1IP0

This is version 1.5 of the entry. See complete history

Literature

Solution structure of betacellulin, a new member of EGF-family ligands.

Miura, K.Doura, H.Aizawa, T.Tada, H.Seno, M.Yamada, H.Kawano, K.

(2002) Biochem Biophys Res Commun 294: 1040-1046

  • DOI: https://doi.org/10.1016/S0006-291X(02)00585-5
  • Primary Citation Related Structures:
    1IOX, 1IP0

  • PubMed Abstract:

    The solution structure of the EGF-like domain of betacellulin (BTCe), a newly discovered member of the epidermal growth factor (EGF) family, has been determined using two-dimensional nuclear magnetic resonance spectroscopy. This is the first report to identify the solution structure of the EGF-family ligand monomers that interact with both ErbB-1 and ErbB-4. The solution structure of BTCe was calculated using 538 NMR-derived restraints. The overall structure of BTCe was stabilized by three disulfide bonds, a hydrophobic core, and 23 hydrogen bonds. It appears that BTCe is comprised of five beta-strands and one short 3(10) helical turn. The secondary structural elements of BTCe are basically similar to those of the other EGF-family proteins, except that several significant variations of the structural properties were found. It is suggested that the structural variations between BTCe and the other EGF-family ligands may affect the specific receptor-recognition properties of EGF-family ligands.


  • Organizational Affiliation
    • Bio-oriented Technology Research Advancement Institution, 1-40-2 Nisshin, Saitama, Saitama 331-8537, Japan.

Macromolecule Content

  • Total Structure Weight: 5.92 kDa
  • Atom Count: 412
  • Modeled Residue Count: 50
  • Deposited Residue Count: 50
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
BETACELLULIN50Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P35070 (Homo sapiens)
Explore P35070
Go to UniProtKB:  P35070
PHAROS:  P35070
GTEx:  ENSG00000174808
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP35070
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 50
  • Conformers Submitted:
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2002-07-31
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2022-02-23
    Changes: Database references, Derived calculations
  • Version 1.4: 2023-12-27
    Changes: Data collection
  • Version 1.5: 2024-11-20
    Changes: Structure summary
