1HY5

CRYSTAL STRUCTURE OF THE CATALYTIC DOMAIN OF YOPE-YERSINIA PESTIS GAP EFFECTOR PROTEIN.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.25 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.197
  • R-Value Observed: 0.176

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Crystal structure of the Yersinia pestis GTPase activator YopE.

Evdokimov, A.G.Tropea, J.E.Routzahn, K.M.Waugh, D.S.

(2002) Protein Sci 11: 401-408

  • DOI: https://doi.org/10.1110/ps.34102
  • Primary Citation of Related Structures:
    1HY5

  • PubMed Abstract:

    Yersinia pestis, the causative agent of bubonic plague, evades the immune response of the infected organism by using a type III (contact-dependent) secretion system to deliver effector proteins into the cytosol of mammalian cells, where they interfere with signaling pathways that regulate inflammation and cytoskeleton dynamics. The cytotoxic effector YopE functions as a potent GTPase-activating protein (GAP) for Rho family GTP-binding proteins, including RhoA, Rac1, and Cdc42. Down-regulation of these molecular switches results in the loss of cell motility and inhibition of phagocytosis, enabling Y. pestis to thrive on the surface of macrophages. We have determined the crystal structure of the GAP domain of YopE (YopE(GAP); residues 90-219) at 2.2-A resolution. Apart from the fact that it is composed almost entirely of alpha-helices, YopE(GAP) shows no obvious structural similarity with eukaryotic RhoGAP domains. Moreover, unlike the catalytically equivalent arginine fingers of the eukaryotic GAPs, which are invariably contained within flexible loops, the critical arginine in YopE(GAP) (Arg144) is part of an alpha-helix. The structure of YopE(GAP) is strikingly similar to the GAP domains from Pseudomonas aeruginosa (ExoS(GAP)) and Salmonella enterica (SptP(GAP)), despite the fact that the three amino acid sequences are not highly conserved. A comparison of the YopE(GAP) structure with those of the Rac1-ExoS(GAP) and Rac1-SptP complexes indicates that few, if any, significant conformational changes occur in YopE(GAP) when it interacts with its G protein targets. The structure of YopE(GAP) may provide an avenue for the development of novel therapeutic agents to combat plague.


  • Organizational Affiliation

    Protein Engineering Section, Macromolecular Crystallography Laboratory, National Cancer Institute at Frederick, Frederick, Maryland 21702-1201, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
YERSINIA PESTIS VIRULENCE PROTEIN YOPE
A, B
136Yersinia pestisMutation(s): 6
Gene Names: YOPE
UniProt
Find proteins for P31493 (Yersinia pestis)
Explore P31493
Go to UniProtKB:  P31493
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP31493
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.25 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.197
  • R-Value Observed: 0.176
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.692α = 90
b = 71.978β = 113.06
c = 62.684γ = 90
Software Package:
Software NamePurpose
SOLVEphasing
SHELXL-97refinement
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2002-02-06
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
