1GG1

CRYSTAL STRUCTURE ANALYSIS OF DAHP SYNTHASE IN COMPLEX WITH MN2+ AND 2-PHOSPHOGLYCOLATE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.209
  • R-Value Observed: 0.211

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure of 3-deoxy-d-arabino-heptulosonate-7-phosphate synthase from Escherichia coli: comparison of the Mn(2+)*2-phosphoglycolate and the Pb(2+)*2-phosphoenolpyruvate complexes and implications for catalysis.

Wagner, T.Shumilin, I.A.Bauerle, R.Kretsinger, R.H.

(2000) J Mol Biol 301: 389-399

  • DOI: 10.1006/jmbi.2000.3957
  • Primary Citation of Related Structures:
    1GG1

  • PubMed Abstract:
  • The crystal structure of the phenylalanine-regulated 3-deoxy-D-arabino-heptulosonate-7-phosphate synthase (DAHPS) from Escherichia coli in complex with Mn(2+) and the substrate analog, 2-phosphoglycolate (PGL), was determined by molecular replacement using X-ray diffraction data to 2 ...

    The crystal structure of the phenylalanine-regulated 3-deoxy-D-arabino-heptulosonate-7-phosphate synthase (DAHPS) from Escherichia coli in complex with Mn(2+) and the substrate analog, 2-phosphoglycolate (PGL), was determined by molecular replacement using X-ray diffraction data to 2.0 A resolution. DAHPS*Mn*PGL crystallizes in space group C2 (a=210.4 A, b=53.2 A, c=149.4 A, beta=116.1 degrees ) with its four (beta/alpha)(8) barrel subunits related by non-crystallographic 222 symmetry. The refinement was carried out without non-crystallographic symmetry restraints and yielded agreement factors of R=20.9 % and R(free)=23.9 %. Mn(2+), the most efficient metal activator, is coordinated by the same four side-chains (Cys61, His268, Glu302 and Asp326) as is the poorly activating Pb(2+). A fifth ligand is a well-defined water molecule, which is within hydrogen bonding distance to an essential lysine residue (Lys97). The distorted octahedral coordination sphere of the metal is completed by PGL, which replaces the substrate, 2-phosphoenolpyruvate (PEP), in the active site. However, unlike PEP in the Pb*PEP complex, PGL binds the Mn(2+) via one of its carboxylate oxygen atoms. A model of the active site is discussed in which PEP binds in the same orientation as does PGL in the DAHPS*Mn*PGL structure and the phosphate of E4P is tethered at the site of a bound sulfate anion. The re face of E4P can be positioned to interact with the si face of PEP with only small movement of the protein.


    Related Citations:
    • Crystal structure of phenylalanine-regulated 3-Deoxy-D-arabino-heptulosonate-7-phosphate synthase from Escherichia coli
      Shumilin, I.A., Kretsinger, R.H., Bauerle, R.H.
      (1999) Structure 7: 865
    • Purification, crystallization, and preliminary crystallographic analysis of 3-deoxy-D-arabino-heptulosonate-7-phosphate synthase from Escherichia coli
      Shumilin, I.A., Kretsinger, R.H., Bauerle, R.
      (1996) Proteins 24: 404

    Organizational Affiliation

    Department of Biology, University of Virginia, Charlottesville, VA 22903-2477, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
3-DEOXY-D-ARABINO-HEPTULOSONATE-7-PHOSPHATE SYNTHASEA, B, C, D350Escherichia coliMutation(s): 0
EC: 4.1.2.15 (PDB Primary Data), 2.5.1.54 (UniProt)
UniProt
Find proteins for P0AB91 (Escherichia coli (strain K12))
Explore P0AB91
Go to UniProtKB:  P0AB91
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
PGA (Subject of Investigation/LOI)
Query on PGA

Download Ideal Coordinates CCD File
E [auth A], I [auth B], M [auth C], Q [auth D]2-PHOSPHOGLYCOLIC ACID
C2 H5 O6 P
ASCFNMCAHFUBCO-UHFFFAOYSA-N
 Ligand Interaction
SO4
Query on SO4

Download Ideal Coordinates CCD File
G [auth A], H [auth A], K [auth B], L [auth B], O [auth C], P [auth C], S [auth D], T [auth D]SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
MN
Query on MN

Download Ideal Coordinates CCD File
F [auth A], J [auth B], N [auth C], R [auth D]MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.209
  • R-Value Observed: 0.211
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 210.357α = 90
b = 53.188β = 116.09
c = 149.392γ = 90
Software Package:
Software NamePurpose
AMoREphasing
CNSrefinement
DENZOdata reduction
SCALEPACKdata scaling
CCP4data scaling

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2000-10-04
    Type: Initial release
  • Version 1.1: 2008-04-26
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
