1G3X

INTERCALATION OF AN 9ACRIDINE-PEPTIDE DRUG IN A DNA DODECAMER


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.7 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.220

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Intercalation of an acridine-peptide drug in an AA/TT base step in the crystal structure of [d(CGCGAATTCGCG)](2) with six duplexes and seven Mg(2+) ions in the asymmetric unit.

Malinina, L.Soler-Lopez, M.Aymami, J.Subirana, J.A.

(2002) Biochemistry 41: 9341-9348


  • PubMed Abstract:
  • We present the crystal structure of an acridine drug derivatized at carbon 9, [N(alpha)-(9-acridinoyl)-tetraarginine], intercalated within the dodecamer [d(CGCGAATTCGCG)](2). The presence of a lateral chain at the central carbon 9 atom differentiates ...

    We present the crystal structure of an acridine drug derivatized at carbon 9, [N(alpha)-(9-acridinoyl)-tetraarginine], intercalated within the dodecamer [d(CGCGAATTCGCG)](2). The presence of a lateral chain at the central carbon 9 atom differentiates this compound from most acridine drugs hitherto studied, which are usually derivatized at carbon 4. The DNA:drug interaction we observe differs from that observed in previous studies, which primarily involves shorter, mainly hexameric sequences, in two important regards: the acridine intercalates within an AA/TT base step, rather than within a CG/CG base step; and the binding site is located at the center of the sequence, rather than at one end of the duplex. In addition, we observe a novel crystal packing arrangement, with six dodecamer duplexes and seven hydrated magnesium ions in the asymmetric unit of a large (66.5 x 68.4 x 77.4 A(3)) unit cell in space group P2(1)2(1)2(1). The duplexes are organized in layers parallel to the ab plane, with consecutive layers crossing each other at right angles.


    Organizational Affiliation

    Departament d'Enginyeria Química, ETSEIB, Universitat Politècnica de Catalunya, Diagonal 647, E-08028 Barcelona, Spain.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
N(ALPHA)-(9-ACRIDINOYL)-TETRAARGININE-AMIDE
M
5N/AN/A
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 1
MoleculeChainsLengthOrganism
5'-D(*CP*GP*CP*GP*AP*AP*TP*TP*CP*GP*CP*G)-3'A,B,C,D,E,F,G,H,I,J,K,L12N/A
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MG
Query on MG

Download SDF File
Download CCD File
A, B, G, J, K, L
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
9AC
Query on 9AC
M
NON-POLYMERC14 H9 N O

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.7 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.220
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 66.471α = 90.00
b = 68.365β = 90.00
c = 77.362γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
REFMACrefinement
DENZOdata reduction
AMoREphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2002-08-16
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
