1CQF | pdb_00001cqf

THE COMPLEX OF THE MUTATED SHIGA TOXIN B SUBUNIT AND GB3 TRISACCHARIDE

• PDB DOI: https://doi.org/10.2210/pdb1CQF/pdb

• Classification: TOXIN
• Organism(s): Escherichia coli
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 1999-08-06 Released: 2000-08-07
• Deposition Author(s): Ling, H., Bast, D., Brunton, J.L., Read, R.J.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free:
  0.200 (Depositor), 0.200 (DCC)
• R-Value Work:
  0.181 (Depositor), 0.182 (DCC)
• R-Value Observed:
  0.181 (Depositor)

Literature

The Complex of the Mutated Shiga Toxin B Subunit and Gb3 Trisaccharide

Ling, H., Bast, D., Brunton, J.L., Read, R.J.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C5  (Explore in 3D)
Global Stoichiometry: Homo 5-mer - A5

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 41.74 kDa
• Atom Count: 3,033
• Modeled Residue Count: 345
• Deposited Residue Count: 345
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
SHIGA TOXIN B-CHAIN	A, B, C, D, E	69	Escherichia coli	Mutation(s): 1
UniProt
Find proteins for P69179 (Enterobacteria phage H19B) Explore P69179  Go to UniProtKB:  P69179

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
alpha-D-galactopyranose-(1-4)-beta-D-galactopyranose-(1-4)-beta-D-glucopyranose	F, G, H, I, J, K	3		N/A
Glycosylation Resources
GlyTouCan: G00059MO GlyCosmos: G00059MO GlyGen: G00059MO

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free:  0.200 (Depositor), 0.200 (DCC)
• R-Value Work:  0.181 (Depositor), 0.182 (DCC)
• R-Value Observed: 0.181 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 62.785	α = 90
b = 73.561	β = 90
c = 83.853	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
AMoRE	phasing
CNS	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2000-08-07
Deposition Author(s): Ling, H., Bast, D., Brunton, J.L., Read, R.J.

Revision History

• Version 1.0: 2000-08-07
  Type: Initial release

• Version 1.1: 2008-04-27
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Version format compliance
• Version 1.3: 2018-04-04
  Changes: Data collection
• Version 2.0: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Atomic model, Data collection, Derived calculations, Structure summary
• Version 2.1: 2021-11-03
  Changes: Database references, Structure summary
• Version 2.2: 2024-11-20
  Changes: Data collection, Structure summary
