1CGU

CATALYTIC CENTER OF CYCLODEXTRIN GLYCOSYLTRANSFERASE DERIVED FROM X-RAY STRUCTURE ANALYSIS COMBINED WITH SITE-DIRECTED MUTAGENESIS


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Work: 0.187
  • R-Value Observed: 0.187

wwPDB Validation   3D Report Full Report



Literature

Catalytic center of cyclodextrin glycosyltransferase derived from X-ray structure analysis combined with site-directed mutagenesis.

Klein, C.Hollender, J.Bender, H.Schulz, G.E.

(1992) Biochemistry 31: 8740-8746

  • DOI: 10.1021/bi00152a009
  • Primary Citation of Related Structures:
    1CGU

  • PubMed Abstract:
  • An X-ray structure analysis of a crystal of mutant Asp229----Ala of cyclodextrin glycosyltransferase from Bacillus circulans (Ec 2.4.1.19) that had been shortly exposed to beta-cyclodextrin showed density corresponding to a maltose bound at the catal ...

    An X-ray structure analysis of a crystal of mutant Asp229----Ala of cyclodextrin glycosyltransferase from Bacillus circulans (Ec 2.4.1.19) that had been shortly exposed to beta-cyclodextrin showed density corresponding to a maltose bound at the catalytic center. The crystal structure was refined to an R-factor of 18.7% at 2.5-A resolution. The catalytic center is defined by homology with the structurally known alpha-amylases and by the observation that mutants Asp229----Ala and Asp328----Ala are almost inactive. By model building, the density-defined maltose was extended to a full beta-cyclodextrin, which then indicated the general locations of seven subsites for glucosyl units. The catalytically competent residues Asp229, Glu257, and Asp328 are at the reducing end of the density-defined maltose. In the unligated wild-type structure, Glu257 and Asp328 form a 2.6-A hydrogen bond between their carboxylates in an arrangement that resembles those of the catalytically competent carboxylates in acid proteases. Presumably, the first catalytic step is an attack of the proton between Glu257 and Asp328 on the oxygen of the glycosidic bond.


    Related Citations:
    • Structure of Cyclodextrin Glycosyltransferase Refined at 2.0 Angstroms Resolution
      Klein, C., Schulz, G.E.
      (1991) J Mol Biol 217: 737
    • Engineering a Heavy Atom Derivative for the X-Ray Structure Analysis of Cyclodextrin Glycosyltransferase
      Klein, C., Vogel, W., Bender, H., Schulz, G.E.
      (1990) Protein Eng 4: 65
    • Molecular Cloning, Nucleotide Sequence and Expression in Escherichia Coli of the Beta-Cyclodextrin Glycosyltransferase Gene from Bacillus Circulans Strain No. 8
      Nitschke, L., Heeger, K., Bender, H., Schulz, G.E.
      (1990) Appl Microbiol Biotechnol 33: 542
    • Three-Dimensional Structure of Cyclodextrin Glycosyltransferase from Bacillus Circulans at 3.4 Angstroms Resolution
      Hofmann, B.E., Bender, H., Schulz, G.E.
      (1989) J Mol Biol 209: 793

    Organizational Affiliation

    Institut für Organische Chemie und Biochemie, Universität, Freiburg im Breisgau, Germany.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
CYCLODEXTRIN GLYCOSYL-TRANSFERASEA684Bacillus circulansMutation(s): 0
EC: 2.4.1.19
Find proteins for P30920 (Bacillus circulans)
Explore P30920
Go to UniProtKB:  P30920
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChainsChain Length2D Diagram Glycosylation3D Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose
B
2 N/A Oligosaccharides Interaction
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CA
Query on CA

Download CCD File
A
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Biologically Interesting Molecules (External Reference) 1 Unique
Entity ID: 2
IDChainsNameType/Class2D Diagram3D Interactions
PRD_900001
Query on PRD_900001
Balpha-maltoseOligosaccharide /  Nutrient

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Work: 0.187
  • R-Value Observed: 0.187
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 94.1α = 90
b = 105β = 90
c = 113.9γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 1994-01-31
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Database references, Derived calculations, Other, Structure summary
