1BRN

SUBSITE BINDING IN AN RNASE: STRUCTURE OF A BARNASE-TETRANUCLEOTIDE COMPLEX AT 1.76 ANGSTROMS RESOLUTION


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.76 Å
  • R-Value Work: 0.190
  • R-Value Observed: 0.190

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Subsite binding in an RNase: structure of a barnase-tetranucleotide complex at 1.76-A resolution.

Buckle, A.M.Fersht, A.R.

(1994) Biochemistry 33: 1644-1653

  • DOI: https://doi.org/10.1021/bi00173a005
  • Primary Citation of Related Structures:
    1BRN

  • PubMed Abstract:

    A set of subsites in barnase has been proposed from kinetic studies. A specific substrate analog, the tetradeoxynucleotide, CGAC, has been designed from this information. We report the crystal structure of its complex with barnase at 1.76-A resolution. The structure was solved by molecular replacement from a model of free barnase and refined to a crystallographic R factor of 19.0%. The stoichiometry of the asymmetric unit dimeric complex is [barnase:d(CGAC)]2, with 2-fold noncrystallographic symmetry. Each barnase molecule binds one oligonucleotide whereby the recognition site is occupied by guanine, and all three phosphate groups of the nucleotide make electrostatic interactions with basic residues in a strongly electropositive region at the bottom of the active site. The active-site His 102 packs against the adenine base of the nucleotide in an almost identical manner to the guanine base in the barnase-d(GpC) complex and defines a possible subsite in the Michaelis complex. The overall protein structure is unchanged on forming the complex with d(CGAC), but there are small differences in the active site and in crystal packing regions. The protein coordinates will be useful for theoretical calculations since some disorder induced by packing constraints in the crystals of the free enzyme are absent in the crystals of the complex. The interface of the dimer is formed by a His 102-adenine-adenine-His 102 face-to-face ring stack directly on the 2-fold axis. The edge of the adenine-adenine stack packs closely onto the face of a 3'-cytosine-3'-cytosine interaction, which has a "base-pair"-like conformation but too great a separation of the bases to form hydrogen bonds. This unusual arrangement is the major stabilizing interaction within the dimeric complex, since there are no direct protein-protein interactions. Using the structure of the complex as a starting point for model building, the nature of the enzyme-substrate and enzyme-transition state complexes is investigated.


  • Organizational Affiliation

    Cambridge Centre for Protein Engineering, Medical Research Council Centre, Cambridge, U.K.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
PROTEIN (BARNASE (E.C.3.1.27.-))C [auth L],
D [auth M]
110Bacillus amyloliquefaciensMutation(s): 0
EC: 3.1.27
UniProt
Find proteins for P00648 (Bacillus amyloliquefaciens)
Explore P00648
Go to UniProtKB:  P00648
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00648
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (5'-D(*CP*GP*AP*C)-3')
A, B
4N/A
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.76 Å
  • R-Value Work: 0.190
  • R-Value Observed: 0.190
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 39.866α = 107.77
b = 54.286β = 89.05
c = 29.607γ = 96.37
Software Package:
Software NamePurpose
X-PLORrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1994-01-31
    Type: Initial release
  • Version 1.1: 2008-05-22
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-11-29
    Changes: Derived calculations
  • Version 1.4: 2024-02-07
    Changes: Data collection, Database references
