Experimental Data Snapshot

  • Resolution: 2.40 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.197
  • R-Value Observed: 0.197

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

This is version 1.4 of the entry. See complete history


Energetic contributions of four arginines to phosphate-binding in thymidylate synthase are more than additive and depend on optimization of "effective charge balance".

Morse, R.J.Kawase, S.Santi, D.V.Finer-Moore, J.Stroud, R.M.

(2000) Biochemistry 39: 1011-1020

  • DOI: https://doi.org/10.1021/bi9918590
  • Primary Citation of Related Structures:
    1BO7, 1BO8, 1BP0, 1BP6, 1BPJ

  • PubMed Abstract:

    In thymidylate synthase, four conserved arginines provide two hydrogen bonds each to the oxygens of the phosphate group of the substrate, 2'-deoxyuridine-5'-monophosphate. Of these, R23, R178, and R179 are far removed from the site of methyl transfer and contribute to catalysis solely through binding and orientation of ligands. These arginines can be substituted by other residues, while still retaining more than 1% activity of the wild-type enzyme. We compared the kinetics and determined the crystal structures of dUMP complexes of three of the most active, uncharged single mutants of these arginines, R23I, R178T, and R179T, and of double mutants (R23I, R179T) and (R178T, R179T). The dramatically higher K(m) for R178T compared to the other two single mutants arises from the effects of R178 substitution on the orientation of dUMP; 10-15-fold increases in for R23I and R178T reflect the role of these residues in stabilizing the closed conformation of TS in ternary complexes. The free energy for productive dUMP binding, DeltaG(S), increases by at least 1 kcal/mol for each mutant, even when dUMP orientation and mobility in the crystal structure is the same as in wild-type enzyme. Thus, the four arginines do not contribute excess positive charge to the PO(4)(-2) binding site; rather, they ideally complement the charge and geometry of the phosphate moiety. More-than-additive increases in DeltaG(S) seen in the double mutants are consistent with quadratic increases in DeltaG(S) predicted for deviations from ideal electrostatic interactions and may also reflect cooperative binding of the arginines to the phosphate oxygens.

  • Organizational Affiliation

    Department of Biochemistry and Biophysics, The University of California at San Francisco, San Francisco, California 94143-0448, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
PROTEIN (THYMIDYLATE SYNTHASE)316Lacticaseibacillus caseiMutation(s): 1
Find proteins for P00469 (Lacticaseibacillus casei)
Explore P00469
Go to UniProtKB:  P00469
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00469
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on UMP

Download Ideal Coordinates CCD File
C9 H13 N2 O8 P
Query on K

Download Ideal Coordinates CCD File
Binding Affinity Annotations
IDSourceBinding Affinity
UMP PDBBind:  1BP0 Kd: 4000 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Resolution: 2.40 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.197
  • R-Value Observed: 0.197
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 79.1α = 90
b = 79.1β = 90
c = 243.3γ = 120
Software Package:
Software NamePurpose
X-PLORmodel building
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2000-01-12
    Type: Initial release
  • Version 1.1: 2007-10-16
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.3: 2021-11-03
    Changes: Database references, Derived calculations
  • Version 1.4: 2023-08-09
    Changes: Data collection, Refinement description
