Experimental Data Snapshot

  • Resolution: 2.00 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.194
  • R-Value Observed: 0.194

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Crystallographic and mutational analyses of an extremely acidophilic and acid-stable xylanase: biased distribution of acidic residues and importance of Asp37 for catalysis at low pH.

Fushinobu, S.Ito, K.Konno, M.Wakagi, T.Matsuzawa, H.

(1998) Protein Eng 11: 1121-1128

  • DOI: https://doi.org/10.1093/protein/11.12.1121
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Xylanase C from Aspergillus kawachii has an optimum pH of 2.0 and is stable at pH 1.0. The crystal structure of xylanase C was determined at 2.0 A resolution (R-factor = 19.4%). The overall structure was similar to those of other family 11 xylanases. Asp37 and an acid-base catalyst, Glu170, are located at a hydrogen-bonding distance (2.8 A), as in other xylanases with low pH optima. Asp37 of xylanase C was replaced with asparagine and other residues by site-directed mutagenesis. Analyses of the wild-type and mutant enzymes showed that Asp37 is important for high enzyme activity at low pH. In the case of the asparagine mutant, the optimum pH shifted to 5.0 and the maximum specific activity decreased to about 15% of that of the wild-type enzyme. On structural comparison with xylanases with higher pH optima, another striking feature of the xylanase C structure was found; the enzyme has numerous acidic residues concentrated on the surface (so-called 'Ser/Thr surface' in most family 11 xylanases). The relationship of the stability against extreme pH conditions and high salt concentrations with the spatially biased distribution of charged residues on the proteins is discussed.

  • Organizational Affiliation

    Department of Biotechnology, University of Tokyo, Japan.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
ENDO-1,4-B-XYLANASE C184Aspergillus luchuensisMutation(s): 0
Gene Names: XYNC
Find proteins for P33557 (Aspergillus kawachii (strain NBRC 4308))
Explore P33557
Go to UniProtKB:  P33557
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP33557
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.00 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.194
  • R-Value Observed: 0.194
  • Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.065α = 90
b = 62.065β = 90
c = 113.291γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
X-PLORmodel building

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1999-01-13
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-08-02
    Changes: Database references, Refinement description
