7CTX

Crystal structure of Arabidopsis thaliana SOBIR1 kinase domain(residues 388-401 deleted) in complex with AMP-PNP and magnesium

• PDB DOI: https://doi.org/10.2210/pdb7CTX/pdb

• Classification: PLANT PROTEIN
• Organism(s): Arabidopsis thaliana
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2020-08-20 Released: 2022-04-27
• Deposition Author(s): Wei, X., Wang, Y.L., Gu, T.Y., Xin, F.J.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.91 Å
• R-Value Free: 0.243
• R-Value Work: 0.225
• R-Value Observed: 0.226

Literature

Crystal structure of Arabidopsis thaliana SOBIR1 kinase domain(residues 388-401 deleted) in complex with AMP-PNP and magnesium

Wei, X., Wang, Y.L., Gu, T.Y., Xin, F.J.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 73.61 kDa
• Atom Count: 4,598
• Modelled Residue Count: 594
• Deposited Residue Count: 646
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Leucine-rich repeat receptor-like serine/threonine/tyrosine-protein kinase SOBIR1	A, B	323	Arabidopsis thaliana	Mutation(s): 0  Gene Names: SOBIR1, EVR, At2g31880, F20M17.8 EC: 2.7.10.1 (PDB Primary Data), 2.7.11.1 (PDB Primary Data)
UniProt
Find proteins for Q9SKB2 (Arabidopsis thaliana) Explore Q9SKB2  Go to UniProtKB:  Q9SKB2

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ANP	C [auth A], E [auth B]	PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER C10 H17 N6 O12 P3 PVKSNHVPLWYQGJ-KQYNXXCUSA-N
MG	D [auth A], F [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.91 Å
• R-Value Free: 0.243
• R-Value Work: 0.225
• R-Value Observed: 0.226
• Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.389	α = 90
b = 50.732	β = 106.65
c = 93.066	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data collection
HKL-2000	data scaling
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2022-04-27
Deposition Author(s): Wei, X., Wang, Y.L., Gu, T.Y., Xin, F.J.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	31571963

Revision History

• Version 1.0: 2022-04-27
  Type: Initial release

• Version 1.1: 2023-11-29
  Changes: Data collection, Refinement description
