4OBI

Crystal structure of a DUF1312 family protein (EF3258) from Enterococcus faecalis V583 at 1.73 A resolution

• PDB DOI: https://doi.org/10.2210/pdb4OBI/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Enterococcus faecalis V583
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2014-01-07 Released: 2014-02-12
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.73 Å
• R-Value Free: 0.199
• R-Value Work: 0.169
• R-Value Observed: 0.170

Literature

Crystal structure of a hypothetical protein (EF3258) from Enterococcus faecalis V583 at 1.73 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 12.17 kDa
• Atom Count: 788
• Modelled Residue Count: 87
• Deposited Residue Count: 106
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A	106	Enterococcus faecalis V583	Mutation(s): 0  Gene Names: EF_3258, I574_00339, NP_816855.1, OO5_00326
UniProt
Find proteins for Q82Z21 (Enterococcus faecalis (strain ATCC 700802 / V583)) Explore Q82Z21  Go to UniProtKB:  Q82Z21

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PG4	B [auth A]	TETRAETHYLENE GLYCOL C8 H18 O5 UWHCKJMYHZGTIT-UHFFFAOYSA-N
ZN	C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.73 Å
• R-Value Free: 0.199
• R-Value Work: 0.169
• R-Value Observed: 0.170
• Space Group: P 2₁ 2₁ 2₁
• Diffraction Data: https://doi.org/10.18430/M34OBI

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 27.259	α = 90
b = 49.16	β = 90
c = 71.776	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
XSCALE	data scaling
REFMAC	refinement
XDS	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2014-02-12
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2014-02-12
  Type: Initial release

• Version 1.1: 2014-12-24
  Changes: Structure summary
• Version 1.2: 2017-11-22
  Changes: Refinement description
• Version 1.3: 2018-01-24
  Changes: Database references
• Version 1.4: 2024-02-28
  Changes: Data collection, Database references, Derived calculations
