1JNY

Crystal structure of Sulfolobus solfataricus elongation factor 1 alpha in complex with GDP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.220
  • R-Value Observed: 0.224

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

The crystal structure of Sulfolobus solfataricus elongation factor 1alpha in complex with GDP reveals novel features in nucleotide binding and exchange.

Vitagliano, L.Masullo, M.Sica, F.Zagari, A.Bocchini, V.

(2001) EMBO J 20: 5305-5311

  • DOI: 10.1093/emboj/20.19.5305
  • Primary Citation of Related Structures:
    1JNY

  • PubMed Abstract:
  • The crystal structure of elongation factor 1alpha from the archaeon Sulfolobus solfataricus in complex with GDP (SsEF-1alpha.GDP) at 1.8 A resolution is reported. As already known for the eubacterial elongation factor Tu, the SsEF-1alpha.GDP structur ...

    The crystal structure of elongation factor 1alpha from the archaeon Sulfolobus solfataricus in complex with GDP (SsEF-1alpha.GDP) at 1.8 A resolution is reported. As already known for the eubacterial elongation factor Tu, the SsEF-1alpha.GDP structure consists of three different structural domains. Surprisingly, the analysis of the GDP-binding site reveals that the nucleotide- protein interactions are not mediated by Mg(2+). Furthermore, the residues that usually co-ordinate Mg(2+) through water molecules in the GTP-binding proteins, though conserved in SsEF-1alpha, are located quite far from the binding site. [(3)H]GDP binding experiments confirm that Mg(2+) has only a marginal effect on the nucleotide exchange reaction of SsEF-1alpha, although essential to GTPase activity elicited by SsEF-1alpha. Finally, structural comparisons of SsEF- 1alpha.GDP with yeast EF-1alpha in complex with the nucleotide exchange factor EF-1beta shows that a dramatic rearrangement of the overall structure of EF-1alpha occurs during the nucleotide exchange.


    Related Citations:
    • Crystallization of a hyperthermophilic archeal elongation factor 1 alpha
      Zagari, A., Sica, F., Scarano, G., Vitagliano, L., Bocchini, V.
      (1994) J Mol Biol 242: 175

    Organizational Affiliation

    Centro di Biocristallografia, CNR, via Mezzocannone 6, I-80134 Naples, Italy.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Elongation factor 1-alphaAB435Saccharolobus solfataricusMutation(s): 0
Find proteins for P35021 (Saccharolobus solfataricus (strain ATCC 35092 / DSM 1617 / JCM 11322 / P2))
Explore P35021
Go to UniProtKB:  P35021
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GDP
Query on GDP

Download Ideal Coordinates CCD File
A, B
GUANOSINE-5'-DIPHOSPHATE
C10 H15 N5 O11 P2
QGWNDRXFNXRZMB-UUOKFMHZSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.220
  • R-Value Observed: 0.224
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.113α = 90
b = 113.718β = 90.2
c = 80.32γ = 90
Software Package:
Software NamePurpose
AMoREphasing
X-PLORrefinement
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2002-01-23
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
