6UU3

E. coli sigma-S transcription initiation complex with a 4-nt RNA and a CTP ("Old" crystal soaked with GTP, ATP, CTP, and ddTTP for 30 minutes)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.00 Å
  • R-Value Free: 0.380
  • R-Value Work: 0.303

wwPDB Validation   3D Report Full Report

Currently 6UU3 does not have a validation slider image.


This is version 1.3 of the entry. See complete history


Literature

Structural Insights into Transcription Initiation from De Novo RNA Synthesis to Transitioning into Elongation.

Zuo, Y.De, S.Feng, Y.Steitz, T.A.

(2020) iScience 23: 101445-101445

  • DOI: https://doi.org/10.1016/j.isci.2020.101445
  • Primary Citation of Related Structures:
    6UTV, 6UTW, 6UTX, 6UTY, 6UTZ, 6UU0, 6UU1, 6UU2, 6UU3, 6UU4, 6UU5, 6UU6, 6UU7, 6UU8, 6UU9, 6UUA, 6UUB, 6UUC

  • PubMed Abstract:

    In bacteria, the dissociable σ subunit of the RNA polymerase (RNAP) is responsible for initiating RNA synthesis from specific DNA sites. As nascent RNA grows, downstream DNA unwinds and is pulled into the RNAP, causing stress accumulation and initiation complex destabilization. Processive transcription elongation requires at least partial separation of the σ factor from the RNAP core enzyme. Here, we present a series of transcription complexes captured between the early initiation and elongation phases via in-crystal RNA synthesis and cleavage. Crystal structures of these complexes indicate that stress accumulation during transcription initiation is not due to clashing of the growing nascent RNA with the σ 3.2 loop, but results from scrunching of the template strand DNA that is contained inside the RNAP by the σ 3 domain. Our results shed light on how scrunching of template-strand DNA drives both abortive initiation and σ-RNAP core separation to transition transcription from initiation to elongation.


  • Organizational Affiliation

    Department of Molecular Biophysics and Biochemistry, Yale University, New Haven, CT 06520, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit alphaA [auth AAA],
B [auth BBB]
242Escherichia coliMutation(s): 0
Gene Names: rpoA_1NCTC9962_06804
EC: 2.7.7.6
UniProt
Find proteins for P0A7Z4 (Escherichia coli (strain K12))
Explore P0A7Z4
Go to UniProtKB:  P0A7Z4
Find proteins for A0A377D9Q8 (Escherichia coli)
Go to UniProtKB:  A0A377D9Q8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7Z4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit betaC [auth CCC]1,342Escherichia coliMutation(s): 0
Gene Names: rpoBZ5560ECs4910
EC: 2.7.7.6
UniProt
Find proteins for P0A8V2 (Escherichia coli (strain K12))
Explore P0A8V2
Go to UniProtKB:  P0A8V2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A8V2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta'D [auth DDD]1,407Escherichia coliMutation(s): 0
Gene Names: rpoCtabBb3988JW3951
EC: 2.7.7.6
UniProt
Find proteins for P0A8T7 (Escherichia coli (strain K12))
Explore P0A8T7
Go to UniProtKB:  P0A8T7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A8T7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit omegaE [auth EEE]90Escherichia coliMutation(s): 0
Gene Names: rpoZb3649JW3624
EC: 2.7.7.6
UniProt
Find proteins for P0A800 (Escherichia coli (strain K12))
Explore P0A800
Go to UniProtKB:  P0A800
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A800
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
RNA polymerase sigma factor RpoSF [auth FFF]336Escherichia coli K-12Mutation(s): 0
Gene Names: rpoSappRkatFnurotsXsigSb2741JW5437
UniProt
Find proteins for P13445 (Escherichia coli (strain K12))
Explore P13445
Go to UniProtKB:  P13445
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13445
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains LengthOrganismImage
Synthetic DNA 50-MER (promoter non-template strand)G [auth 111]50synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains LengthOrganismImage
Synthetic DNA 50-MER (promoter template strand)H [auth 222]50synthetic construct
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 8
MoleculeChains LengthOrganismImage
RNA 4-merI [auth 333]4synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CTP
Query on CTP

Download Ideal Coordinates CCD File
N [auth DDD]CYTIDINE-5'-TRIPHOSPHATE
C9 H16 N3 O14 P3
PCDQPRRSZKQHHS-XVFCMESISA-N
D4M
Query on D4M

Download Ideal Coordinates CCD File
O [auth 333][(5R)-5-(5-METHYL-2,4-DIOXO-3,4-DIHYDROPYRIMIDIN-1(2H)-YL)-2,5-DIHYDROFURAN-2-YL]METHYL DIHYDROGEN PHOSPHATE
C10 H13 N2 O7 P
XLPGURCDSRIXFL-JGVFFNPUSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
J [auth DDD],
K [auth DDD]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
L [auth DDD],
M [auth DDD]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.00 Å
  • R-Value Free: 0.380
  • R-Value Work: 0.303
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 132.555α = 90
b = 153.578β = 90
c = 231.214γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report

Currently 6UU3 does not have a validation slider image.



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM22778
Howard Hughes Medical InstituteUnited States--

Revision History  (Full details and data files)

  • Version 1.0: 2020-08-26
    Type: Initial release
  • Version 1.1: 2020-09-02
    Changes: Database references
  • Version 1.2: 2022-03-16
    Changes: Author supporting evidence, Database references
  • Version 1.3: 2023-10-11
    Changes: Data collection, Refinement description
