3CT8

Crystal structure of a putative glyoxalase (NP_243026.1) from Bacillus halodurans at 2.10 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3CT8/pdb

• Classification: LYASE
• Organism(s): Halalkalibacterium halodurans C-125
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2008-04-11 Released: 2008-04-29
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free: 0.246
• R-Value Work: 0.216
• R-Value Observed: 0.217

Literature

Crystal structure of a Putative Glyoxalase (NP_243026.1) from Bacillus halodurans at 2.10 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration, light scattering

Macromolecule Content

• Total Structure Weight: 17.45 kDa
• Atom Count: 1,152
• Modelled Residue Count: 133
• Deposited Residue Count: 146
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative glyoxalase	A	146	Halalkalibacterium halodurans C-125	Mutation(s): 0  Gene Names: NP_243026.1, BH2160
UniProt
Find proteins for Q9KAX6 (Halalkalibacterium halodurans (strain ATCC BAA-125 / DSM 18197 / FERM 7344 / JCM 9153 / C-125)) Explore Q9KAX6  Go to UniProtKB:  Q9KAX6

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN	B [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
UNL	C [auth A]	Unknown ligand PTFCDOFLOPIGGS-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free: 0.246
• R-Value Work: 0.216
• R-Value Observed: 0.217
• Space Group: P 4₁ 2₁ 2
• Diffraction Data: https://doi.org/10.18430/M33CT8

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.38	α = 90
b = 51.38	β = 90
c = 116.47	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
XDS	data reduction
SHARP	phasing
SHELXD	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2008-04-29
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2008-04-29
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
