2HEY

Crystal structure of murine OX40L bound to human OX40

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.221
  • R-Value Observed: 0.223

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history.


Literature

The Crystal Structure of the Costimulatory OX40-OX40L Complex.

Compaan, D.M., Hymowitz, S.G.

(2006) Structure 14: 1321-1330

  • DOI: 10.1016/j.str.2006.06.015
  • Primary Citation of Related Structures:
    2HEV, 2HEY, 2HEW

  • PubMed Abstract:

    • OX40 is a T cell costimulator activated by OX40L. Blockade of the OX40L-OX40 interaction has ameliorative effects in animal models of T cell pathologies. In order to better understand the interaction between OX40 and OX40L, we have determined the crystal ...

    OX40 is a T cell costimulator activated by OX40L. Blockade of the OX40L-OX40 interaction has ameliorative effects in animal models of T cell pathologies. In order to better understand the interaction between OX40 and OX40L, we have determined the crystal structure of murine OX40L and of the human OX40-OX40L complex at 1.45 and 2.4 A, respectively. These structures show that OX40L is an unusually small member of the tumor necrosis factor superfamily (TNFSF). The arrangement of the OX40L protomers forming the functional trimer is atypical and differs from that of other members by a 15 degrees rotation of each protomer with respect to the trimer axis, resulting in an open assembly. Site-directed changes of the interfacial residues of OX40L suggest this interface lacks a single "hot spot" and that instead, binding energy is dispersed over at least two distinct areas. These structures demonstrate the structural plasticity of TNFSF members and their interactions with receptors.

    Organizational Affiliation:

    Department of Protein Engineering, Genentech, Incorporated, 1 DNA Way, South San Francisco, California 94080, USA.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Tumor necrosis factor ligand superfamily member 4 F, G152Mus musculusMutation(s): 0
Gene Names: Tnfsf4, Ox40l, Txgp1l
Find proteins for P43488 (Mus musculus)
Explore P43488
Go to UniProtKB:  P43488
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Tumor necrosis factor receptor superfamily member 4 R, T146Homo sapiensMutation(s): 0
Gene Names: TNFRSF4, TXGP1L
Find proteins for P43489 (Homo sapiens)
Explore P43489
Go to UniProtKB:  P43489
NIH Common Fund Data Resources
PHAROS:  P43489
GTEx:  ENSG00000186827
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4
Download Ideal Coordinates CCD File
R
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.221
  • R-Value Observed: 0.223
  • Space Group: H 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 104.729α = 90
b = 104.729β = 90
c = 478.161γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
AMoREphasing

Structure Validation

View Full Validation Report


View more in-depth experimental data

Entry History

Deposition Data

  • Deposited Date: 2006-06-22
  • Released Date: 2006-08-29
    • Deposition Author(s): Hymowitz, S.G.

Revision History

  • Version 1.0: 2006-08-29
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Advisory, Version format compliance
