1WL7

Structure of the thermostable arabinanase

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.183
  • R-Value Observed: 0.183

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history.


Literature

Structural basis for thermostability of endo-1,5-alpha-L-arabinanase from Bacillus thermodenitrificans TS-3.

Yamaguchi, A., Tada, T., Wada, K., Nakaniwa, T., Kitatani, T., Sogabe, Y., Takao, M., Sakai, T., Nishimura, K.

(2005) J Biochem 137: 587-592

  • DOI: 10.1093/jb/mvi078
  • Primary Citation of Related Structures:
    1WL7

  • PubMed Abstract:

    • The crystal structure of a thermostable endo-1,5-alpha-L-arabinanase, ABN-TS, from Bacillus thermodenitrificans TS-3 was determined at 1.9 A to an R-factor of 18.3% and an R-free-factor of 22.5%. The enzyme molecule has a five-bladed beta-propeller fold. The substrate-binding cleft formed across one face of the propeller is open on both sides to allow random binding of several sugar units in the polymeric substrate arabinan ...

    The crystal structure of a thermostable endo-1,5-alpha-L-arabinanase, ABN-TS, from Bacillus thermodenitrificans TS-3 was determined at 1.9 A to an R-factor of 18.3% and an R-free-factor of 22.5%. The enzyme molecule has a five-bladed beta-propeller fold. The substrate-binding cleft formed across one face of the propeller is open on both sides to allow random binding of several sugar units in the polymeric substrate arabinan. The beta-propeller fold is stabilized through a ring closure. ABN-TS exhibits a new closure-mode involving residues in the N-terminal region: Phe7 to Gly21 exhibit hydrogen bonds and hydrophobic interactions with the first and last blades, and Phe4 links the second and third blades through a hydrogen bond and an aromatic stacking interaction, respectively. The role of the N-terminal region in the thermostability was confirmed with a mutant lacking 16 amino acid residues from the N-terminus of ABN-TS.

    Organizational Affiliation:

    Research Institute for Advanced Science and Technology, Osaka Prefecture University, Sakai, Osaka 599-8570.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
arabinanase-TS A312Geobacillus thermodenitrificansMutation(s): 0
Gene Names: abn-ts
EC: 3.2.1.99
Find proteins for Q93HT9 (Geobacillus thermodenitrificans)
Explore Q93HT9
Go to UniProtKB:  Q93HT9
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CA
Query on CA
Download Ideal Coordinates CCD File
A
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.183
  • R-Value Observed: 0.183
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 40.27α = 90
b = 77.81β = 90
c = 89.68γ = 90
Software Package:
Software NamePurpose
CNSrefinement
DENZOdata reduction
SCALEPACKdata scaling
AMoREphasing

Structure Validation

View Full Validation Report


View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-06-21
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
