1RTO

PROTON NMR ASSIGNMENTS AND SOLUTION CONFORMATION OF RANTES, A CHEMOKINE OF THE CC TYPE


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Submitted:

wwPDB Validation   3D Report Full Report

Currently 1RTO does not have a validation slider image.


This is version 1.3 of the entry. See complete history


Literature

Proton NMR assignments and solution conformation of RANTES, a chemokine of the C-C type.

Skelton, N.J.Aspiras, F.Ogez, J.Schall, T.J.

(1995) Biochemistry 34: 5329-5342

  • DOI: https://doi.org/10.1021/bi00016a004
  • Primary Citation of Related Structures:
    1RTN, 1RTO

  • PubMed Abstract:

    1H NMR has been used to investigate the structural properties of RANTES, a protein from the C-C branch of the chemotactic cytokine family that has a strong chemoattractive effect on monocytes, lymphocytes, and eosinophils. Titration of pH from 5.0 to 2.5 indicates that RANTES is extensively aggregated in solution above pH 4.0. At pH 3.7 the protein is mostly dimeric, although this species does dissociate to the monomer with a Kd of 35 microM. NMR data have been acquired and resonance assignments made for the dimeric species. Structures of the dimer have been generated by distance geometry and simulated annealing calculations that utilized 1956 intramolecular distance restraints, 120 intermolecular distance restraints, 164 dihedral angle restraints, and 68 restraints enforcing 34 hydrogen bonds (17.0 restraints per residue). The structure is well-defined (average root mean square deviation from the average structure of 0.38 +/- 0.06 and 0.53 +/- 0.12 A for backbone heavy atoms of residues 4-66 of the monomer and dimer, respectively). Each monomer consists of a C-terminal alpha-helix packing against a three-stranded antiparallel beta-sheet and two short N-terminal beta-strands; dimerization occurs between the N-terminal regions of each monomer. This quaternary structure is very different from that of the C-X-C chemokines such as interleukin-8 and melanoma growth stimulatory activity but similar to that found for the C-C chemokine macrophage inflammatory factor 1 beta. Distinct structural differences between RANTES and other chemokines at both the tertiary and quaternary level are discussed with regard to the distinct biological functions of the C-C and C-X-C members of this protein family.


  • Organizational Affiliation

    Department of Protein Engineering, Genetech, Inc., South San Francisco, California 94080, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
RANTES
A, B
68Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P13501 (Homo sapiens)
Explore P13501
Go to UniProtKB:  P13501
PHAROS:  P13501
GTEx:  ENSG00000271503
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13501
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Submitted:

Structure Validation

View Full Validation Report

Currently 1RTO does not have a validation slider image.



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1995-06-03
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2022-03-02
    Changes: Database references, Derived calculations, Other
